SHT-330 Servo Driven Sheeter

This product has been discontinued and removed from our shelves.

SHT-330 offline sheeter is part of our label finishing products which incorporate an imported system controller and servo motors for unwinding, feeding, sheeting, and rewinding. With a speed of 180 repetitions a min, the servo-driven sheeter is an efficient and stable machine.

Features

1. Automatic web guider: smoothly feeds and rewinds paper
2. Full servo system for feeding, dispensing, and rewinding paper
3. Easy set up: preset parameters for the number of meters, labels, speed, and when to stop
4. Brush press unit makes it easy to rewind rolls
5. Tag rejects is an optional system where the machine automatically stops during inspection and marks any defective rolls

Parameters
Max Speed 300m /min
Max Web Width 330mm
Max Unwinding Dia 500mm
Max Rewinding Dia 450mm
Overall (L*W*H) 1750mm x 11000mm x 1200mm
Weight 1000kg
Option

1. Automatic inspection system. E+L or AVT
2. Sheet collection system
